LM3915 LED Dot/Bar Display Driver IC DIP-18 Package

The LM3915 LED Dot/Bar Display Driver IC in a DIP-18 package is a versatile and efficient solution for driving LED displays in either bar or dot mode. This IC is designed to provide a smooth, linear output corresponding to an input voltage, making it ideal for applications like audio level indicators, battery meters, and other visual display systems. The LM3915 LED Dot/Bar Display Driver IC DIP-18 Package features an integrated reference voltage and offers precise control over the brightness and scaling of the LEDs, allowing for easy customization.

Note:

1. Product Images are shown for illustrative purposes only and may differ from the actual product.
2. For Technical Specifications about the IC go through the Datasheet in the Attachment section.


Features:

1. Dot/Bar Mode Selection: Supports both dot and bar display modes for flexible visual output.
2. Linear LED Control: Provides a linear voltage-to-LED brightness relationship, ensuring accurate and smooth scaling.
3. Drives Up to 10 LEDs: Capable of driving 10 LEDs, ideal for various visual display applications.
4. Analog or Digital Input: Accepts both analog and digital input signals for versatile application use.
5. Integrated Reference Voltage: Built-in reference voltage for easy operation and consistent LED display scaling.

Package Includes:

1 x LM3915 LED Dot/Bar Display Driver IC DIP-18 Package
